Voigtlander 28mm f1.5 VM Nokton ASPH Type II Black

The COLOR SKOPAR 50mm F2.2 is a manual focus standard lens optimized for full size VM mount sensors. Cosina lens designers succeeded in reducing the exterior lens barrel length to only 30mm, despite this being a 50mm F2.2 standard lens.

High performance optics using 7 elements in 6 groups including 3 elements of anomalous partial dispersion glass achieve excellent optical performance even wide open at F2.2. It is possible to focus beyond the minimum rangefinder distance of 0.7 m and up to 0.5 m with the interlocking of the rangefinder. It is effective when shooting with a camera equipped with a live view function.

It comes with a compact, straight-type hood that is shaped so that it does not obstruct the rangefinder camera rangefinder window.

Aspheric high speed wide-angle lens and integrated, non-detachable, lens hood.

Focal Length: 21 mm
Aperture Ratio: 1:1,8
Minimum Aperture: F 22
Lens Construction: 13 elements in 11 groups
Angle of View: 91?
Aperture Blades: 10
Minimum Focus: 0,5 m
Maximum Diameter: 69 mm
Length: 78,4 mm
Mount: M-Bajonett (VM)
Weight: 412 g
Filter Size: 58 mm
Color: black
Others: integrated lenshood (not detachable),
Optional: ---

State of the art lens with a wonderful Bokeh, in brass (silver)

Focal Length: 35 mm
Aperture Ratio: 1:1,7
Minimum Aperture: F 16
Lens Construction: 9 elements in 7 groups
Angle of View: 62?
Aperture Blades: 10
Minimum Focus: 0,5 m
Maximum Diameter: 53 mm
Length: 50,6 mm
Mount: M-Bajonett (VM)
Weight: silver 330 g, black 238 g
Filter Size: 46 mm
Color: silver
Others: standard lens hood
Optional: Lenshood LH-9S (silver), LH-9B (black)

This lens is specially designed for manual focusing coupled precisely with the camera?s optical rangefinder system. Compared with a single lens reflex camera finder, the rangefinder focusing system focuses wide angle lenses with much more precision, enabling the photographer to use the shallow depth of focus offered by the large maximum aperture with peace of mind. The lens couples with the camera?s rangefinder from infinity down to 0.70m (differs depending on the camera) and features a helicoid that enable the lens to focus down to a minimum focus distance of 0.50m. The feature really shows its strengths when shooting using a camera with live view functionality. The included bayonet type rectangular hood is stylish, effective at shielding stray light and can be easily attached to and removed from the lens.

You may ask why this lens has been announced - when Voigtlander already have a 50mm f1.1. The 50mm f1.2 is a brand new lens design, with a similar specification to the exceedingly popular 40mm f1.2 VM lens.

This lens features two aspherical elements & a 12 aperture blade diaphragm - allowing exceptional performance from F22 all the way to wide open.

The 50mm f1.2 is designed for use with both digital and film photography and is equipped with a rangefinder coupling cam. The minimum close focus distance of this lens is 70cm.

Both the LH-8 and LH-10 lens hoods can be used with this lens. The LH-10 is a brand new lens hood designed for this lens, though you can also use the more compact LH-8.

Main Features:
Enhanced high performance aspherical lens surfaces
Extremely solid and durable all-metal barrel
Manual focus
12 aperture blades
VM Bayonet Mount
Focus coupling system
Minimum focus distance: 70

The Voigtlander 75mm F1.9 ULTRON VM is a manual focus medium telephoto lens optimized for full-frame M mount sensors. The newly designed optics consists of 7 elements in 5 groups, 3 of which are made of cutting-edge partial-dispersion glass technology, which both suppresses chromatic aberration and ensures high image quality.

The balance between bokeh and resolution has been optimized by deliberately leaving a moderate amount of spherical aberration. While maintaining the clarity of the image areas which are in focus, the out-of-focus area produces a rich and large bokeh effect.

The new but simple construction allows all the elements to move in tandem, resulting in an overall length of only 54.1 mm, which is extremely compact for a 75mm lens. The lens thus offers excellent portability and also suppresses vignetting in the frame when used on rangefinder cameras. This lens is equipped with a high-precision rangefinder-coupled mechanism, and the full-metal helicoid ring provides a silky smooth luxurious focus.

The Single Coated version of the lens is finished in Gloss black paint

The minimum focusing distance is 0.5m, allowing extremely close focus, beyond even many rangefinder mechanically-linked focus-ranges.

Following the success of the E-Mount 40mm f1.2, here is the VM mount version. Optically the same as the E-Mount but slightly adjusted so it can be worked by both film and digital platforms.

Main Features:

Enhanced high performance aspherical lens surfaces
Extremely solid and durable all-metal barrel
Manual focus
10 aperture blades
VM Bayonet Mount
Focus coupling system
Minimum focus distance: 50cm

Focal Length:\01140mm
Aperture Range:\011f1.2 - f22
Elements / Groups:\0113 / 3
Angle of View:\01155?
Focusing Range:\0110.5m
Lens Type:\011Standard
Lens Coverage:\011Full Frame / 35mm
Lens Focus Mechanism:\011Manual
Adaptor Ring / Lens Filter Thread: 52mm
Compatible Lens Hood:\011LH-8 (Sold Separately)
Lens Colour:\011Black
Dimensions:\01160.8mm x 43.3mm
Lens Weight:\011315g

The new redesigned compact Ultron Vintage Line 28mm F2.0 Aspherical VM Type I features improved aspherical optical performance utilising10 lens elements in 7 groups. The new lens is sharper, smaller, lighter and available in three classic lens style.



Type I lenses have 1950?s Chrome and Black styling with a retro quick focusing knob. The lens accepts optional aluminium LH-4N and LH-12 lens hoods. Sold separately

The Voigtlander 50mm f3.5 APO-LANTHAR Type I is an extremely high performance manual focus standard lens optimized for full frame VM mount cameras. The apochromatic design thoroughly eliminates chromatic aberration on axis and other aberrations, while pursuing ultimate performance in terms of resolution and contrast reproduction. While adopting a maximum aperture of F3.5, the lens is composed of eight elements in six groups, four of which are made of anomalous partial dispersion glass to achieve uncompromising optical performance.

The lens combines ultimate optical performance with easy handling and classic vintage rangefinder lens styling. As a tribute to classic rangefinder lenses that appeared in the mid 20th century, the more expensive vintage style straight slot screw heads were chosen instead of less expensive modern Phillips head.

Equipped with a high precision rangefinder linked mechanism, and the silky feel of the all metal helicoid allowing the photographer to experience the true joy of focusing using a traditional rangefinder. The minimum focusing distance of the Type I is 0.45m. The rangefinder close focus is 0.7m (depending upon camera capability), which is linked to the rangefinder. A mechanism is provided to recognize the junction point of the rangefinder linked range by a clicking sensation during focusing operation.

The filter diameter is a retro inspired φ34mm. Two versions of Type I are available: a two tone black paint and chrome model with a heavy feel using brass materials (body weight: 245g) and a lightweight model with a matte black paint and aluminium construction (body weight: 150g). Each version includes a metal hood and a metal cap with the same finish as the lens body.

The Voigtlander COLOR-SKOPAR 28mm F2.8 Aspherical VM is a high-performance wide-angle lens focused on light handling for rangefinder cameras. The latest optical design and aspherical lens elements maintain the same optical performance as our Voigtländer ULTRON Vintage Line 28mm F2 Aspherical VM, while keeping the maximum aperture at F2.8 to achieve extreme portability.

Type I has a nostalgic appearance thanks to the use of a rotating helicoid system, and a brass lens exterior. It is available in black paint and silver finishes.

All models have extremely compact exteriors, and the lenses combine the mobility of a rangefinder camera with the beautiful design of a snap-shooter. The optical system consists of 8 elements in 5 groups, including one double-sided aspheric lens. The lens has been optimized for use with rangefinder-linked digital and film cameras.

The NOKTON Vintage Line 35mm F1.5 Aspherical is a regular use lens for rangefinder cameras with a large aperture. Still, the filter diameter is kept to φ39mm and the overall length of the product is short at 36mm, giving it a tight, compact portability.

The lens barrel, with a modern classic design, is equipped with a 6-group, 9-element optical system featuring two double-sided aspheric lenses, which provide excellent optical performance at all apertures.

The minimum focusing distance is 0.5m, shorter than the 0.7m linked to the rangefinder (depending on the camera to which it is attached).

Two styles are available: First, there is Type I, made of aluminum and weighing 188g having both light weight and maximum portability. Also offered is Type II, made of brass and weighing 284g for a sturdy and substantial feeling, with a finish choice of either black or silver.

The optional hoods LH-4N with slits and LH-12 classic style are both compatible.

Aspheric hyper-wide-angle lens with integrated lens hood

Focal Length: 10 mm
Aperture Ratio: 1:5,6
Minimum Aperture: F 22
Klick Stop: 1/2
Lens Construction: 13 elements in 10 groups
Angle of View: 130?
Aperture Blades: 10
Minimum Focus: 0,5 m
Maximum Diameter: 67,8 mm
Length: 58,7 mm
Mount: M-bayonet (VM)
Weight: 312 g
Filter Size: n/a
Color\011black
Others\011Lens hood (non-detachable),Pressure fit cap
Optional\011---

Classic pancake wide-angle lens.

Focal Length: 35 mm
Aperture Ratio: 1:2,5
Minimum Aperture: F 22
Lens Construction: 7 elements in 5 groups
Angle of View: 63?
Aperture Blades: 10
Minimum Focus: 0,7 m
Maximum Diameter: 55 mm
Length: 23 mm
Mount: M-Bajonett (VM)
Weight: 134 g
Filter Size: 39 mm
Color: black
Others: rangefinder can be combined
Optional: Lenshood LH-4N

The Voigtlander COLOR-SKOPAR 28mm F2.8 Aspherical L39 is a high-performance wide-angle lens focused on light handling for rangefinder cameras. The latest optical design and aspherical lens elements maintain the same optical performance as our Voigtländer ULTRON Vintage Line 28mm F2 Aspherical VM, while keeping the maximum aperture at F2.8 to achieve extreme portability.

Type I has a nostalgic appearance thanks to the use of a rotating helicoid system, and a brass lens exterior. It is available in black paint and silver finishes.

All models have extremely compact exteriors, and the lenses combine the mobility of a rangefinder camera with the beautiful design of a snap-shooter. The optical system consists of 8 elements in 5 groups, including one double-sided aspheric lens.

High speed wide lens
M.C. = multi coated

Focal Length: 40 mm
Aperture Ratio: 1:1,4
Minimum Aperture: F 16
Lens Construction: 7 elements in 6 groups
Angle of View: 56?
Aperture Blades: 10
Minimum Focus: 0,7 m
Maximum Diameter: 55 mm
Length: 29,7 mm
Mount: M-Bajonett (VM)
Weight: 175 g
Filter Size: 43 mm
Color: black
Others: rangefinder can be combined
Optional: Lenshood LH-6
